Every technology in Cinema production has its peculiarities...

the goal is to look forward how to mix them to create something new, something special...

DJI™ RONIN™ 2 + Matrix SLED = Matrix R2

Ultra smooth gimbal 5-AXIS CNC Machined
Completely Tool Free
40mm (1.57") telescopic carbon fiber post
[from 530mm (20.86") to 940mm (37.00")]

Exclusive Monitor Stabilization System
Your monitor will be always horizontal
no matter what is the angle of the sled post

Unique Ronin™ 2 tilt-able Battery plate
Use them as standard battery on a sled
NO EXTERNAL cable to power your favourite gimbal
The MAGIC is all INSIDE the sled

Thanks to Ronin™2 YAW Locker forget the annoying sound
when used in PAN Lock mode.
The exclusive Ronin™2 Plate adapter let you mount
the gimbal securely to the Sled Post

The modularity of Matrix Sleds let you mount
the micrometric topstage used for camera
on the lower part of the sled to obtain
a perfect balance of the whole system.

An useful advantage: It can be reconfigured to became a standard Sled with all the bells and whistels of a pro system

The micrometric non floating topstage with
automatic locking system
can be installed on its original position in seconds

The Vlock or 3Studs Battery plate,
equipped with 1/4 and 3/8 threaded holes,
can be mounted on standard position over the
RONIN™2 Battery plate adapter

The Horizon system can be detached to let a standard
monitor mount* to be attached to the sled

and of course, the lower part can be equipped with C-Battery
like PRO Sled or Extreme Sled

*in bundle with Matrix R2

All product names, logos, and brands are property of their respective owners

Matrix Sled R2

Professional Sled with 40mm Telescopic Post designed to work with DJI™ Ronin™2 thanks to the Ronin2 Plate adapter included in the bundle
No external cable needed to power Ronin2. Forget the umbilical cable era
The standard Ronin™2 Battery can be attached as regular batteries with the ability to move fore-aft on carbon fiber rods and to tilt +90° -90° for perfect Balance
Horizon Monitor system included in the bundle
The topstage can be assembled directly on the lower part of the sled to grant ultra precision balancing with the Standard VLock or 3Studs battery plate included in the bundle

In the bundle:

1x Matrix R2 Telescopic post with 40mm of diameter. From 530mm (collapsed) to 940mm (fully extended) range
1x Micrometric head able to be fixed on the upper part as on lower part of the sled
1x Ronin™2 Plate Adapter for Matrix Sled
1x Ronin™2 Battery holder (tilt-able from +90° to -90° – 100mm distance centre-to-centre of 15mm carbon fiber rods)
1x Ronin™2 Yaw Locker
1x Extended Docking Bracket for a perfect balancing (static and dynamic)
1x Vlock or 3Studs Plate with 1/4 and 3/8 threaded holes and Push Pull connectors (fuse protected)
SmartCAM Horizon system with separate hard case
1x Standard monitor holder as fixed replacement of SmartCAM Horizon
1x Hard Case

Please Note : DJI Ronin2 not included in this bundle

Matrix Sled R2 with Vlock battery mount quantity		Matrix Sled R2 with Vlock battery mount SKU: 000006146 EAN: 8051411191186	€ 10,382.14 In stock (can be backordered)
Matrix Sled R2 with 3Studs battery mount quantity		Matrix Sled R2 with 3Studs battery mount SKU: 000008085 EAN: 8051411191919	€ 10,467.54 In stock (can be backordered)

Matrix Sled R2
